Laboratory freeze-dryer
Floor-mounted unit in compact design for demanding applications
Delta 2-24 LSCplus
Freezing and drying inside the ice condenser (single-chamber method) on ten heatable shelves, optionally with a fan
Condenser capacity: 24 kg
Condenser temperature: –85 °C
| Controller | LSCplus |
| Method | Single-chamber |
| Max. number of shelves | 10 |
| Shelf diameter | 200 mm |
| Total shelf area | 0,31 m² |
| Shelf temperature | –40 °C to +60 °C |
Delta 2-24 LSCplus
Freezing and drying inside the ice condenser (single-chamber method) on four heatable shelves with stoppering device, optionally with a fan
Condenser capacity: 24 kg
Condenser temperature: –85 °C
| Controller | LSCplus |
| Method | Single-chamber |
| Max. number of shelves | 4 |
| Shelf diameter | 250 mm |
| Total shelf area | 0,18 m² |
| Distance between shelves | 45 mm to 110 mm |
| Max. capacity for 2R Vials | 600 |
| Stoppering device | Yes |
| Shelf temperature | –40 °C to +60 °C |
Delta 2-24 LSCplus
Two drying chambers with a total of 24 connections for round-bottom flasks, wide-neck bottles or ampoule distributors
Condenser capacity: 24 kg
Condenser temperature: –85 °C
| Controller | LSCplus |
| Method | Double-chamber |
| Max. connections | 24 |
Delta 2-24 LSCplus
Ten heatable shelves, additional connections for twelve round-bottom flasks, wide-neck bottles or ampoule distributors
Condenser capacity: 24 kg
Condenser temperature: –85 °C
| Controller | LSCplus |
| Method | Double-chamber |
| Max. number of shelves | 10 |
| Shelf diameter | 200 mm |
| Total shelf area | 0,31 m² |
| Distance between shelves | 25 mm |
| Max. connections | 12 |
Delta 2-24 LSCplus
Four heatable shelves with stoppering device
Condenser capacity: 24 kg
Condenser temperature: –85 °C
| Controller | LScplus |
| Method | Double-chamber |
| Number of shelves | 4 |
| Shelf diameter | 250 mm |
| Total shelf area | 0,18 m² |
| Distance between shelves | 45 mm to 110 nn |
| Max. capacity for 2R Vials | 600 |
| Stoppering device | Yes |
Delta 2-24 LSCplus
Eight heatable shelves; optional lifting device for drying chamber available
Condenser capacity: 24 kg
Condenser temperature: –85 °C
| Controller | LSCplus |
| Method | Double-chamber |
| Max. number of shelves | 8 |
| Shelf diameter | 375 mm |
| Total shelf area | 0,88 m² |
| Distance between shelves | 48 mm |
Basic device
Compact, mobile unit for effective lyophilisation of specimens with innovative Wireless Shelf technology. The freeze dryer can be configured with tried and tested accessories to meet your specific needs. The simple and intuitive LSCplus controller supports manual and automatic process control for reproducible results.
Two different drying methods are available to handle virtually every task. –85 °C for specimens with low eutectic points.
24 kg
-85 °C
860 x 1050 x 650 mm
Product Specifications
| Ice condenser capacity | 24 kg |
|---|---|
| Ice condenser temperature | -85 °C |
| Dimensions of base model (W x H x D) | 860 x 1050 x 650 mm |
| Weight | 250 kg |
| Communication port | Ethernet |
